FLEXICS® CHAIN 911

Download PDF

Add to inquiry

Download PDF

To inquiry
Description
Description
Design
Technical Data
Contact

PP/PUR drag chain cable, unscreened

Automation and Motor Supply Cables

Extremely flexible PP/PUR control cable for transmission of instrumentation and control signals for machine building and plant construction purposes, especially for continuous moving machine parts, e.g. within C-tracks. FLEXICS® CHAIN 911 cables are designed for both indoor and outdoor applications when exposed to high mechanical stress. Resistant against a wide range of oils, greases, coolants and lubricants.

This product has 56 option(s)

Cable image - FLEXICS® CHAIN 911
Cable image
Cable image
Cable image
Description
Description
Design
Technical Data
Contact

Options

Add to inquiry
Number of cores x nominal cross-section (mm²)
Outer diameter appr. (mm)
Cu-value (kg/km)
Total weight appr. (kg/km)
2 x 0.5
5
9.7
33
3 G 0.5
5.2
14.4
40
4 G 0.5
6.5
19
54
5 G 0.5
7
24
62
7 G 0.5
7.7
33.6
76
12 G 0.5
9.1
58
114
18 G 0.5
11
86
165
25 G 0.5
13.2
120
218
2 x 0.75
5.6
14.4
42
3 G 0.75
5.9
21.6
50
4 G 0.75
6.7
29
61
5 G 0.75
7.2
36
72
7 G 0.75
8.8
50
100
12 G 0.75
10.2
86
158
18 G 0.75
12.2
130
219
25 G 0.75
15.4
180
314
2 x 1
6
19.2
48
3 G 1
6.5
29
61
4 G 1
7.2
38.4
72
5 G 1
7.7
48
93
7 G 1
9.5
67
122
12 G 1
11.2
115
196
18 G 1
13.7
173
278
25 G 1
17.2
240
385
36 G 1
20.1
346
625
41 G 1
22
410
779
50 G 1
24
498
953
65 G 1
27.2
650
1205
2 x 1.5
6.7
28.8
68
3 G 1.5
7.3
43
83
4 G 1.5
7.9
48
102
5 G 1.5
9
72
128
7 G 1.5
10.6
101
177
12 G 1.5
12.5
173
275
18 G 1.5
15.2
259
405
25 G 1.5
19
360
562
36 G 1.5
22.2
518
880
42 G 1.5
24
628
1209
50 G 1.5
26.2
749
1449
3 G 2.5
8.8
72
122
4 G 2.5
9.8
96
163
5 G 2.5
11
120
196
7 G 2.5
13.3
168
268
12 G 2.5
15.8
288
446
18 G 2.5
18.8
432
665
25 G 2.5
24
600
932
4 G 4
12.8
154
240
5 G 4
14.1
192
298
7 G 4
16.9
269
418
4 G 6
14.9
230
354
7 G 6
19
403
610
4 G 10
18.4
384
685
5 G 10
20.7
480
817
7 G 10
24.7
672
1023
4 G 16
21.3
614
1042
5 G 16
23.8
768
1292

Technical changes reserved.

All figures are therefore without guarantee.
